| Video-Based Access Control for Dedicated Charging Bays | Using smart cameras and AI algorithms, the system accurately identifies vehicles occupying charging bays and triggers automated parking locks. This ensures that charging spaces remain reserved exclusively for electric vehicles—effectively preventing internal combustion engine (ICE) vehicles from taking up these spots—and boosts charging station utilization by 50%. | Intelligent Guidance for Tidy Cable Management | Smart cameras combined with voice-guided prompts encourage users to properly stow charging cables and connectors. This ensures a neat, organized setup, addresses common operational challenges, and keeps charging stations tidy at all times. | Smart Advertising for Additional Revenue | Transform charging stations into high-value media assets with 24/7 continuous ad displays. An intelligent ad-delivery system enables targeted, on-demand content, turning the time spent waiting for a charge into new business opportunities and creating a stable, secondary revenue stream for operators. | Robust Protection for Enhanced Safety | Built with an IP55 dustproof/waterproof rating and an IK10 impact-resistance rating, the equipment is designed to withstand harsh weather and external physical force. It also features triple-layer detection—monitoring for smoke, water ingress, and tipping—with automatic power-cut and alarm functions to ensure comprehensive charging safety.
| Main technical parameters | |||
|---|---|---|---|
| Charging Equipment | |||
| Power | 120kW | 160kW | 180kW | 240kW | ||
| Installation method | floor-mounted | ||
| Dimensions | H1943mm*W910mm*D531mm | ||
| Input voltage | AC380V±15% | ||
| Input frequency | 50±5Hz | ||
| Output current | 5-400A | 5-500A | ||
| Output voltage | 200VDC~1000VDC | ||
| Cable length | 5M(Customizable) | ||
| Steady current accuracy | ≤±1% | ||
| Ripple factor | ≤±1% | ||
| Power factor | ≥99% | ||
| Conversion efficiency | ≥95% | ||
| Number of muzzles | 2(Customizable single gun) | ||
| Functional Design | |||
| Human-computer interaction | 10-Inch touch screen | ||
| Charging mode | charging by swiping card/ charging by scanning code/VIN code charging/password charging/plug and play |
||
| Function upgrade mode | USB、OTA | ||
| Communication mode | Ethernet/4G | ||
| Environmental Indicators | |||
| Operating temperature | –30℃~+60℃ | ||
| Operating humidity | 5%~95%(RH), No condensation | ||
| Operating altitude | ≤2000m | ||
| Degree of protection | IP55 | ||
| Cooling method | Forced air cooling | ||
| Safety Design | |||
| Safety standards | GB/T 18487.1-2023、GB/T 20234.3-2023、GB/T 27930-2023、GB/T 34657.1-2017、NB/T 33001-2018 | ||
| Protection function | Input / output over-current ( overload ) protection, short-circuit protection, output over-voltage protection, input over / under-voltage protection, over-temperature protection, insulation monitoring, gun wire disconnection protection, dumping protection, water immersion protection, smoke protection, ground continuity protection, leakage protection |
||
240kW–720kW Air-CooledFully Liquid-Cooled Split-Type DC Charging Station
Develop an integrated urban system for solar power, energy storage, EV charging, and parking to enhance operational efficiency.
